ASX6000LNP-256GT-C
SPECIFICATIONS
| Model | ASX6000LNP-256GT-C |
| Capacity | 256GB |
| NAND Flash | 3D NAND |
| Interface | PCIe Gen3x4 |
| Form Factor | M.2 2280 |
| MTBF | 1,800,000 hours |
| Dimensions (L x W x T) | 22 x 80 x 2.15mm |
| Power Consumption | 0.33W Active (Typical) 0.14W Slumber (Typical) (*measured by power meter) |
| Operating Temperature | 0°C~70°C |
| Storage Temperature | -40°C~85°C |
| Shock Resistance | 1500G/0.5ms |
| Certifications | RoHS, CE, FCC, BSMI, VCCI, KC |
| Warranty | 3 Years |
FEATURES
- Ultra-fast PCIe Gen3x4 interface:R/W speed up to 1800/1200MB/s
- NVMe 1.3 support
- 3D NAND Flash for higher capacity and durability
- Advanced LDPC ECC Technology
- HMB (Host Memory Buffer) and SLC Caching
- Compact M.2 2280 form factor – ideal for high-end desktops, notebooks and Ultrabooks
